Arcam A15+ Integrated amplifier
The Arcam A15+ is an updated version of the Arcam A15, featuring a more powerful and refined power supply, enhanced Bluetooth 5.4 with Snapdragon Sound and Auracast support, and other internal circuitry improvements for better sound quality and performance. While both are Class AB amplifiers, the A5+ has lower power supply impedance, reduced interference, and better control over low-level dynamics, resulting in a quieter background and more poised, detailed sound
With a wide array of analogue inputs, including a meticulously tuned phono stage, and digital inputs including HDMI eARC, the A15+ provides an impact for everything from vinyl to TV.
- ARCAM Class AB amplification – provides brilliant musicality
- 2x 80W Power Output – powers loudspeakers with dynamics.
- Wireless audio with Snapdragon Sound and Auracast built-in – for the best sound with the most convenience
- Wired or Wireless Headphones – connect your headphones for quiet listening with, or without wires
- HDMI eARC/ARC input
- Fine-tuned phono stage – ensures your records sound as detailed and engaging as possible
- Plastic Free Packaging – for easy disposal of natural materials
Specifications
Continuous power output (0.5% THD), per channel
2 channels driven, 20Hz – 20kHz, 8Ω 80W
2 channels driven, 1kHz, 4Ω 120W
Harmonic distortion, 80% power, 8Ω at 1kHz 0.002%
Analogue Inputs
Number of inputs: 3 (RCA pairs)
Signal/noise ratio: (A-wtd, ref. 50W, 1V input) 106dB
Frequency response: 20Hz—20kHz ± 0.2dB
Phono (MM) Input
Input impedance: 47kΩ + 100pF
Frequency response (ref. RIAA curve): 20Hz—20kHz ± 1dB
Digital Inputs
Supported Sample Rates (kHz):
192, 176.4, 96, 88.2, 48, 44.1
Bit depths (bit) 24, 16
Frequency response (filter 1) 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) 109dB
Headphone Output
Maximum output level (RMS) into 32Ω/300Ω 2.5V/5Vrms
Load range 16Ω – 2kΩ
Wireless Specifications
Bluetooth – 5.4 aptX HD, Auracast two way also sends to headphones
General
Mains voltage 100V or 110–120V or 220–240V, 50–60Hz
Dimensions W x D (including speaker terminals) x H (including feet) 431 x 344 x 98mm
Weight (net) 10kg
Weight (packed) 13kg
Supplied accessories
Remote control with 2 x AAA batteries
